Working Principle
All laboratory analysis equipment work with an vibration motor drive. This drive produces a 3D throwing motion that moves the material to be sieved equally over the whole sieving surface. Multi-layer standard lab analysis test sieve with timer is a new and precision equipment for continuously selecting / sifting / testing the powder. It uses the new type vibrating motor as the source of vibration. It is usually equipped with Φ100mm, Φ200mm,Φ300mm standard sieve.We can also produce the test sieve according to the customer's requirements.
Machine Type
We offer three common models: Ultrasonic Test Sieve, All-Copper Test Sieve, and Slap Sieve Shaker.
The Ultrasonic Test Sieve is ideal for difficult-to-screen materials and fine mesh applications.
The All-Copper Test Sieve is suitable for general-purpose materials.
The Slap Sieve Shaker is designed for materials that tend to clog easily.
If you are unsure which equipment best fits your materials, please provide us with your material details. We will recommend the most suitable model for you and offer a favorable price.
Product Parameters
Main features:
1) Low noise,light weight
2) The platform operation without fixed.
3) Multi-layer screen can be installed, up to 8 layers.
4) We offer customized lab test sieve shaker.if you have special request, contact customer service.
| Items |
Name |
Unit |
Data |
| 1 |
Layers |
Layer |
1-8 |
| 2 |
Diameter |
mm |
Φ200 Φ300 Φ400 |
| 3 |
Sieves Diameter |
mm |
Φ75 Φ100 Φ200 Φ300 Φ400 |
| 4 |
Granularity |
mm |
0.038-3 |
| 5 |
Noise |
db |
<50 |
| 6 |
Feeding Capacity(once) |
g |
<200g/ml |
| 7 |
Amplitude |
mm |
<5 |
| 8 |
Voltage |
v |
110/220/230 |
| 9 |
Speed |
r/min |
1420 |
| 10 |
Powder |
kw |
0.125 |
| 11 |
Overall Dimension |
mm |
450*415*800 |
| 12 |
Weight |
kg |
45 |
Application Industry
Widely used in food, medicine, chemicals, abrasives, pigments, mining, metallurgy, geology, ceramics, defense and other industries research institutes, laboratories, laboratory, production control, testing and analysis.
Packaging & Shipping
Packaging Details:We offer free, Professiona,fumigation-free,and standards wooden case according to product size,and 1 set/case.If you have special equipment please just inform us.
Delivery Time:7-10 working days after payment.
Company Profile
Company Information
Xinxiang Dayong Vibratory Equipment Co., Ltd. is covering an area of 6000 square meter and having more than 20 employees, the company has passed through CE quality management system certification, formed the perfect operation and management system in design and development, product manufacturing, market promotion, equipment installation and after sales service.
FAQ
Pls confirm and provide below information to us before making an exact solution and price for you for Automatic analysis lab test sieve shaker.
Q: What information do I need to provide us to getting an accurate quotation for Standard laboratory test sieve shaker machine?
A: 1. Your material's name, bulk density, and water content.
2. How many layers are you need? And what's the screen mesh size for each layer?
3. Voltage and frequency.
Q: How long for the delivery time?
A: 5-10 working days for conventional products.
Q: How long for warranty time?
A: 12 months from the shipping date.
